• Helirotor™ compressor is direct drive, low
speed (3600 rpm). The only moving parts are
the rotors and load/unload mechanisms for
high reliability and efficiency.
• Two independent rotary refrigerant circuits.
• Tracer™ Chiller Controller and the Adaptive
Control™ microprocessor provide all unit
control and safety functions in a proactive
control strategy
Evaporator Data
Design Flow Rate 240 gpm
Pressure Drop 14.4
Fluid Water
Condenser Data
Ambient Temperature 95° F
Compressor
Scrollt 2
Refrigeran R22
Flow Rate
Minimum 118 w/pump
Maximum 406 w/ pump
Electrical
Requirements 460 V | 3 Phase | 60 H
Fuse Sizer 250 Amps
Dimensions
Width x Length xHeight 102x240x105 in.
Weight 11,750 lbs.
