• Fits through a doorway
• Variable speed drive on fan to control air flow
• Very quiet at any fan speed
• 3-way fork lift pockets and removable casters for easy plascement
• Water coil approved to 250 PSI
• Steam coil approved to 75 PSI
• One or two 20″ discharge ducts avaialble – diffuser or custom outlet connections available
Water Connection 1.5″ Victaulic
Power Requirements 480 V | 3 phase | 10 amp
Power Connection Leviton CS-81-65C (male on AH)
Air Flow 5,500 CFM
Cooling, 20 tons BTU/hr 250,000
Hot Water Heat BTU/hr 600,000
Steam BTU/hr 384,000
Width x Length xHeight 32x67x52 in.
Discharge Duct Diameter 20″
Weight 1,130 lbs.
