• Heavy Duty Welded Construction
• 50’ Remote Thermostat
• Arctic Wiring – Good for -80°F
• Electronic Flame Safety Control
• Caster Wheels & Lifting Eye
• Y-Strainer & Gas Pressure Regulator
• High & Low Temperature Shutdown
• Purge Cycle for Greater Safety
• Fireye Flame Safeguard
Burner Capacity 990,000 BTU
Airflow 5,000 CFM
Firing Direct Fired Make Up Air With Hi Low Fire
Fuel Natural Gas or Vapor Propane
Gas Pressure 1/2 psi min, Specify Available Gas
and Pressure When Ordering
Power 208 – 240 Vac / 60 Hz / 1 Phase
208 – 240 / 480 Vac / 60 Hz / 3 Phase
Full Load 18A @ 240 Vac / 1 Phase
10A @ 240 Vac / 3 Phase
5A @ 480 Vac / 3 Phase
Air Discharge 18” Round Outlet
Discharge Temp. 190°F @ 0°F Ambient
Weight 720 Lbs.
Dimensions 85” (L) X 34” (W) X 47” (H)
